Product Description
Product Features
1. This product integrates audio-video decoding and microphone effect processing. It features:
2 analog stereo inputs
1 optical (OPT) digital input
1 coaxial (COAX) digital input
2 microphone inputs
USB playback
Bluetooth functionality
HDMI ports: 3 inputs and 1 output
The HDMI OUT supports ARC (Audio Return Channel). HDMI audio transmission supports both I2S and SPDIF.
2. Audio output modes:
Pass-through, 2.1, 5.1, 7.1
3. Supports 5.1 audio decoding formats.
4. HDMI version and supported formats:
HDMI version 2.0
Supports HDCP 1.4 and HDCP 2.2
Maximum video resolution: 4K×2K @ 50/60Hz
Supported audio sampling rates: 32K, 44.1K, 48K, 88.2K, 96K, 192K
5. Microphone effect processing includes integrated:
Effects processor
Feedback suppressor
Equalizer
Crossover
Limiter
Dynamic EQ
It processes music and microphone signals digitally, offering flexible effect handling and output configuration, ideal for karaoke applications, especially in professional KTV environments. All functions can be adjusted via PC software connected through USB or RS232 port.
Dimensions (W×D×H): 435 × 320 × 80mm
Weight: 4.5kg
