Product Description

• 32-Channel Audio Matrix Controller
• 8 Audio Inputs & 32 Audio Outputs
• 32-Zone Speaker Selection & Paging Control
• Built-In Weekly Timer for Scheduled Announcements
• Independent Zone Volume Control
• Output Attenuation Control
• Up to 64 Zones Expandable with 1 Master + 7 Slave Controllers
• Supports Up to 5 Remote Paging Microphones
• Master / Slave Configuration via DIP Switch
• Live, Individual, Group & All-Zone Paging
• RJ45 Call Station Inputs
• Alarm Input & Output Interface
• 128 × 64 LCD Display
• Frequency Response: 60 Hz – 16 kHz (±3 dB)
• Power Consumption: 20 W
• Power Supply: AC 230 V, 50–60 Hz
• Dimensions: 484 × 390 × 132 mm
• Net Weight: 7.1 kg
