Product Description

• 8 Channel Line Inputs – For connecting audio source devices
• 8 Channel Audio Outputs – For connecting power amplifiers
• 1 MIC Input – 600Ω, 1V unbalanced
• 1 Alarm Input (EMC) – For receiving alarm signals
• Individual Volume Control – Each channel has individual volume control
• Line / MIC Selection – Each channel has individual controller to switch
• Frequency Response: 60Hz–18kHz
• THD: <0.01% @ 1kHz
• Power Supply: AC220V
• Power Consumption: 10~15W
• Protection: AC FUSE (0.5A) ×2
• Dimensions: 485 × 390 × 90mm
• Net Weight: 7.05Kg
• Rack-mount design – For background music/paging and PA system installations
